Introduction to Electrical Schematics

Introduction to Electrical Schematics

This is the first lesson in the Electrical Print Reading Course. This lesson teaches about input, logic, and output devices, and the state in which symbols are drawn on electrical schematics.

Clear

SKU: ITC.EPR_1ESC Category: Tag:

Course Overview

This course was designed to provide training for electricians, mechanics, and others, wanting to know more about electrical print reading. The eight lessons in this course present general information about electrical schematics and electrical diagrams showing and explaining how to read and interpret the symbols on an electrical schematics and electrical diagrams.

Module Overview

This is the first lesson in the Electrical Print Reading Course. This lesson teaches about input, logic, and output devices, and the state in which symbols are drawn on electrical schematics.

Module Objectives

  • Name the three groups of input devices.
  • Describe the function of the input element of a control circuit.
  • Describe the function of the logic element of a control circuit.
  • Describe the function of the output element of a control circuit.
  • Describe the state in which symbols are drawn on electrical schematics.
*A one-year SkillGRID subscription is required for all new users, billed at $12/year.
